KLF-SH152 Corn Grain Harvester Gearbox Agricultural Speed Increase Bevel Gear Reducer

Name: KLF-SH152 Corn Grain Harvester Gearbox Agricultural Speed Increase Bevel Gear Reducer
Brand: Kadiva
Rating: 5.0 (49 reviews)

KLF-SH152 speed multiplier gearbox for corn grain harvester headers. 1:1.04 ratio, 80kW power, standard spline interface. Direct replacement for imported models, durable and impact-resistant, with customization available.

Model:
KLF-SH152
Brand:
Kadiva

Availability:

Quantity:



Inquire Add to Basket

Product Description

The KLF-SH152 gearbox is a dedicated speed-increasing bevel gear reducer specially designed for corn kernel harvesting machines, engineered to match the power transmission demands of corn picker agricultural equipment.

Gear Ratio: 1:1.04 (Speed Increase Type)
Rated Input: 1400rpm, 80KW /109Hp, 546N.m
Rated Output: 1460rpm, 523N.m
Application: Corn Grain Harvester / Corn Picker Farm Machinery
